– Chuẩn IEEE 802.3af/at PoE Standard.
– 04 x 10/100Mbps Auto-Negotiation and Auto-MDIX Fast Ethernet 2*RJ45 Ports.
– Chống sét lan truyền cấp độ 2 cho các cổng Uplink.
– Hỗ trợ khoảng cách truyền dẫn lên đến 250m (Tốc độ 10 Mbps).
Mô tả
4-port 10/100M PoE Switch ONV H1064PLS
– Dòng ONV H1064PLS là Switch AI PoE Unmaneged 10/100M do ONV phát triển độc lập.
– Cổng 1-4 có thể hỗ trợ IEEE802.3af ở PoE tiêu chuẩn. Công suất PoE cổng đơn đạt 30W và công suất đầu ra PoE tối đa là 65W.
– Là thiết bị cấp nguồn PoE, switch có thể tự động phát hiện và nhận biết thiết bị nhận nguồn đạt tiêu chuẩn và cấp nguồn qua cáp mạng. Switch poe ONV có thể cấp nguồn cho thiết bị đầu cuối POE như AP không dây, webcam, điện thoại VoIP, xây dựng hệ thống liên lạc điều khiển truy cập trực quan thông qua cáp mạng.
Thông số kỹ thuật
Model
H1064PLS
Interface
Fixed Port
4*10/100Base-TX PoE ports (Data/Power)
2*10/100Base-TX uplink RJ45 ports (Data)
Ethernet Port
Port 1-6/1-10 can support 10/100Base-TX auto-detection, full/half-duplex MDI/MDI-X auto-sensing
Functional Switch
1*(100m: default 100 meters transmission, 250m: Extend and VLAN transmission mode)
Twisted Pair Transmission
10BASE-TX: Cat5 or later UTP(≤250 meters)
100BASE-TX: Cat5 or later UTP(≤100 meters)
Chip Parameter
Network Management Type
Unmanaged
Network Protocol
IEEE802.3 10BASE-T, IEEE802.3i 10Base-T, IEEE802.3u 100Base-TX IEEE802.3x
Forwarding Mode
Store and Forward (Full Wire Speed)
Switching Capacity
1.6Gbps (Non-blocking)
Forwarding Rate@64byte
0.98Mpps
MAC
1K
Buffer Memory
768K
Jumbo Frame
1536byte
LED Indicator
Power: PWR (Green), Network: Link(Yellow), PoE: PoE (Green)
Functional switch: EXTEND (Green)
PoE & Power Supply
PoE Port
Port 1-4
Power Supply Pin
1/2(+) 3/6(-)
Max Power Per Port
30W, IEEE802.3af/at
Total PWR / Input Voltage
65W/ (AC100-240V)
Power Consumption
Standby<3W, Full load<65W
Power Supply
Built-in power supply, AC100~240V 50-60Hz 1.0A
Physical Parameter
Heat Dissipation
No Fan natural cooling
Operation TEMP/ Humidity
-20~+55°C, 5%~90% RH Non condensing
Storage TEMP/ Humidity
-40~+75°C, 5%~95% RH Non condensing
Dimension (L*W*H)
142*115*40mm
Weight
0.6kg
– Bảo hành: 12 tháng.
